Diathonite Sismactive

Eco-Tech Building Solutions

Diathonite Sismactive

Diathonite Sismactive is a structural thermal mortar: M10 strength (10.1 N/mm² compressive) in a cork-based plaster at λ 0.065 W/mK. In CRM systems it reinforces masonry against seismic loads while...

Diathonite Sismactive is a structural thermal mortar: M10 strength (10.1 N/mm² compressive) in a cork-based plaster at λ 0.065 W/mK. In CRM systems it reinforces masonry against seismic loads while insulating the wall.. Lime-based, breathable and A1 fire-rated; 3–5 cm in CRM builds, on historic and modern masonry inside and out.

Key Features

  • Flexural strength 2.3 N/mm²
  • Compressive category CS IV
  • 40-minute workability
  • Adhesion ≥ 0.5 N/mm² to masonry
$308.50

Size

Made to Order · 6-8 weeks lead time
Secure checkout
Free shipping on orders $1000+
Expert support

Technical Details

Specifications

Technical Performance

Product specifications

Technical Documents

9 documents

Certifications

7 certifications

Key Features

Product highlights

Application

How to apply

Coverage & Yield

Application rates

FAQs

Common questions

Product Brochure

Download PDF

Technical Performance

Yield (±10%) 6.00 kg/m² per 10 mm of thickness (3.12 lb/ft² per inch of thickness)
Aspect Powder
Colour Light grey
Density 600 ± 10% kg/m³ (37.46 ± 0.62% lb/ft³)
Grain Size 0 – 3 mm (0 - 0.12 in)
Minimum Thickness for Application 15 mm (0.6 inches)
Application Thickness for CRM Systems 30 - 50 mm (1.18 – 1.96 inches)
Application Temperature +5 / +30 °C (+41 / +95 °F)
Workability Time (UNI EN 1015-9 – method B) 40 min
Drying Time (T=23°C; U.R. 50%) 10-15 days
Compressive Strength 10.1 N/mm² (EN 998-1, category CS IV) (1464.88 lbf/in²) (EN 998-2 M10)
Flexural Strength 2.3 N/mm² (UNI EN 1015-11) (333.59 lbf/in²)
Thermal Conductivity (λ) 0.065 W/mK (UNI EN 12664)
Specific Heat Capacity (c) 1000 J/kgK/ 0.239 kcal/kg°C (UNI EN 1745, UNI EN 10456)
*Hardened Material Weigh 800 ± 10% kg/m³ (49.94 ± 0.62% lb/ft³)
Storage 12 months
Packaging Paper Bag
Weight 25 kg (55.11 lb)

Technical Documents

  • Diathonite Sismactive Technical data sheet

    Download
  • Diathonite Sismactive Technical specification

    Download
  • Diathonite Sismactive Safety data sheet

    Download
  • Diathonite Sismactive Declaration of performance EN 998 1 CE

    Download
  • Diathonite Sismactive Declaration of performance BS 998 1 UKCA

    Download
  • Diathonite Sismactive Declaration of performance EN 998 2 CE

    Download
  • Diathonite Sismactive Declaration of performance BS 998 2 UKCA

    Download
  • Diathonite Sismactive LEED WELL

    Download
  • EPD Documentation Diathonite

    Download

Certifications

Key Features

  • Flexural strength 2.3 N/mm²
  • Compressive category CS IV
  • 40-minute workability
  • Adhesion ≥ 0.5 N/mm² to masonry

Application

  • Trowel
  • Plastering Machine
  • Coverage & Yield

    Package: 25 kg (55 lbs)

    Coverage / Yield:
    • 6.0 kg/m² per 10 mm (± 10 %)
    • 3.12 lb/ft² per inch (± 10 %)

    Application Range:
    Minimum 15 mm (0.6 in) | CRM System 30–50 mm (1.18–1.96 in)

    Per 25 kg (55 lb) Package:
    • At 15 mm ≈ 2.8 m² (30 ft²)
    • At 30 mm ≈ 1.4 m² (15 ft²)
    • At 50 mm ≈ 0.83 m² (9 ft²)

    Frequently Asked Questions

    What is Diathonite Sismactive used for?
    It's designed for seismic reinforcement and structural stabilization of masonry walls in historic and existing buildings.

    Can it be used in heritage buildings?
    Yes — its breathability and compatibility with old masonry make it ideal for restoration and retrofit projects.

    How thick should it be applied?
    Typically 15–30 mm, depending on structural and insulation needs. Can be applied in multiple layers.

    Do I need a primer?
    It depends on the substrate.
    Use Aquabond on smooth, non-absorbent surfaces (e.g., concrete, painted walls, plasterboard).
    Not needed on absorbent masonry (brick, stone, old plaster).

    How is it installed?
    By hand trowel or spray machine. We recommend professional installation for structural applications.

    Is it fire-resistant?
    Yes — classified as A1 (non-combustible) under EN 13501-1.

    Can I paint over it?
    Yes — once cured, it can be painted with mineral or lime-based paints. We recommend Decork Design for a seamless, eco-friendly finish.
